SHEET 01 · BONDING PATTERNS
Every brick wall is one of nine ideas, repeated.
Pick the bond to see how it's laid, what it costs, and where it fails. Photographed on real walls, specified like the institute sheets.
-
Cagliari Cathedral Is the Best Gothic Gateway Match
Its lateral gate is documented as Gothic, but reviewed sources do not verify it as brick-built, so identification and material require separate answers.
-
Choose a Chimney Block for the Full Assembly
Labels such as "8 x 8" and "8 x 12" may identify an intended liner fit, an opening or another supplier-specific convention rather than exterior dimensions.
-
4 Meanings of Chimney Bricks and Where They Belong
Documented refractory products belong on specified high-heat surfaces. Exterior assemblies use suitable full-depth masonry, and thin veneer is only a finish.
-
Solid Brick Wall: What It Is and How to Identify It
A solid brick wall can have no visible headers because some use concealed metal ties or other bonding arrangements instead.
-
Where Does Granite Come From? Geology and Quarries
It crystallizes from magma underground, but a block may be quarried in one country, processed in another and fabricated near the final project.
-
Brick-to-Brick Wall Ties Vary by Wall Type
In remedial work, the inner-leaf fixing, cavity or separation span, and outer-leaf fixing are three separate performance zones.
-
Kiln Bricks Differ by Type, Grade, Shape and Use
Matching external dimensions and thickness is not enough when grooves, penetrations, controls, holders, or element routing differ.
-
Limewash Paint on Brick If the Surface Is Ready
Traditional limewash generally cannot bond directly to conventional paint or sealer. Surface checks show when to repair, use a test patch or choose another coating.
-
Norman Brick Is a Family of Elongated Formats
The face is commonly 11⅝, 12 in. long and about 2¼ in. high, but the label also covers full-depth brick, thin veneer, concrete veneer and tile.
-
A Fireplace Lintel Is Structural, Even When Concealed
It may sit behind brick, stone, tile or plaster. Cracks, rust, gaps and sagging warrant investigation, but appearance alone cannot diagnose the cause.
-
What Was Blind Veterans UK's Early-19th-Century London HQ?
St John's Lodge was the separate, later headquarters and is the building reported as dating from the early 19th century.
-
Z Bar Flashing: How It Works and What Changes by Joint
Measure the upper leg for the drainage layer, the middle depth for the joint or projection and the lower leg for the drip edge before choosing a profile.
